CCD positioning automatic screen printing machine
Product Features
- Fully automated production: 4-6 pieces per minute
- CCD positioning: fast and accurate
- CCD is driven by motor: X, Y axis can move and memorize the position
- CCD unilateral compensation: CCD can do offset compensation on either side, the alignment is faster and more accurate
- Exclusive patented PIN positioning, accurate and fast alignment
- The Platen lift replaces the PIN lift: Avoid scratches during glass gripping
- Automatic double scraper compensation: CCD Monitor the position, perform numerical compensation quickly and accurately, and prevent ink from entering the printing holes of the blocking point screen.
- With tooth fork feeding and discharging machine: stream into automatic line, greatly reducing the space for equipment placemen
- Exclusive patented removable screen: After the screen is pulled out and cleaned, it will be accurately placed in its original position, with a repeatability (positioning precision) of ±0.02mm.
- Electric scraper head: automatic scraper level correction, depth pressure controlled by motor, numerical input, the scratching process is stable and not jittery
- The scraping seat is driven by servo motor: the process of scraping is stable and does not shake.
- Reinforced platen: to ensure that the platen is not dented and deformed.
- Steel structure printing arm: high strength and no deformation, to ensure stable and no shaking during the scraping process.
- Production history: it will automatic Uploading to the cloud. it also can track production conditions and improve printing quality
- 999 sets of parameters can be memorized: parameters are automatically placed when the part number is called, saving manual setting time
Specification Table
| GLB-M9595 | CCD positioning automatic screen printing machine |
|---|---|
| Substrate size | 300*200～950*950mm (short side feeding) |
| Substrate thickness | 0.6～1.5mm |
| Substrate material | Glass/Film/Optical Acrylic (PMMA) |
| Feeding method | Manual feeding / can be matched with mechanical arm(robot) |
| Discharging method | Manual discharging / can be matched with mechanical arm(robot) |
| Positioning method | 2CCD/4CCD |
| CCD stroke | 280*180～950*450mm |
| Printing Table Specifications | 1100*1300mm |
| Screen size | 1300*1300～1600*1600mm |
| Scratch stroke | 1100 mm(max) Numerical setting |
